Description
JBL DSP Amplifier is an audio processor for fine-tuning of aftermarket audio systems. It is a self-contained audio system with 4-channel audio inputs, 4-channel powered audio outputs, 2-channel pre-amp outputs, easy to use tuning interface and detailed tuning capabilities to satisfy any enthusiast. 31-band parametric or graphic EQ adjustment, assignable input to output mixer with input channel summing, channel gain, master volume control, clipping indicator to ensure the audio output is not distorted and ability to save up to 10 presets.
Specifications:
- Max Power: 200W peak
- RMS Power Output @ 4Ω: 25W x 4, <10% THD+N
- Full-Range Pre-Amp Outputs: 2-channel
- Variable crossovers with hi-pass, lo-pass, band-pass capability & adjustable 0-to-48dB slopes
- Selectable EQ adjustment
- Parametric or Graphic: Selectable 12V/Signal Sense/DC Offset turn-on modes, with 12V remote output
- Frequency Response: 10Hz to 22kHz @ -3dB
- Signal-to-Noise Ratio: >80dB @ 4Ω
- Fuse Rating: 15A
- Operating Voltage: 8V to 16V
